» Home » Products » PP Film Blowing Machine » PP Film Blowing Machine, 1000mm

Polypropylene Film making machine, price and quality good from Ruihua Printing Packing Machinery Co., Ltd.

This machine is suitable for PP(polypropylene) film blowing.



This machine is suitable for PP(polypropylene) film blowing.


Main Technical Variables

Diameter of screw:Φ65mm

L/D ratio of screw: 1:28

Rotation speed of screw stem: 0-120rpm

Qyt.&size of die head:Rotating die head,1pcs,Φ350mm(High-precision hard chrome plating byquenched and tempered treatment),rotating way:360°rotation

Thickness of film: 0.01-0.1mm(Thickness of single layer)

Max. Film width: 1000mm

Main motor: 22kw with inverter control  380V, 50Hz

Total power: 50kw

Max.output: 80kg/h

Overall dimension(L*W*H):4500×2800×4500mm


Extruding part

Single screw extrude head

Material of screw and barrel: 38CRMOALA(zhoushan)

Manual change filter device, 45 steel hot treat

Heating control region: 6 zones

Gear box: 180 Hardening teeth surface gear reducer


Take-up part

High precision hard chromed roller and rubber roller, width: 900mm.

Take up speed:0-50m/min

Take up motor: 2.2kw with frequency inverter control


Winding parts

Winding way: Center Winding(single)

Winding motor: 1 set torque adjust speed motors

Winding roller : 2 pieces


If need more details, please contact

Fern Chen

Ruian Ruihua Printing Packing Machinery Co.,Ltd.

Address: Nanyu Road, Beiyu Industrial Area, Shangwang Street, Ruian,Zhejiang,China

Tel: +86 577 65165355

Mob: +86 18957702100

Whatsapp/Viber/Wechat: +86 18958856105

Skype: live:fern_chen_91_1
