This machine is suitable for various roll materials roll to roll printing, like regular paper, kraft paper, thermal paper, film(BOPP,OPP,CPP,PET,PE), non woven cloths, woven bags, self-adhesive labels, paper cups, etc.

Main

1. Easy operation, flexible starting, accurate color register.

2. Machine is withmeter counter. Working meter can be preset, machine will stop when reached the preset length or the material is cut off.

3. The printing cylinder is lift and down pneumatically, it will automatically stir the printing ink after lifting.

4. Withmetal anilox rollerfor ink transfer, printing ink be even. The roller is with surface chromed treatment.

5. Withelectric heating way, and unit temperature control(thermostatic) system.

6. With hot air and cold air blowing system for fast ink drying, reliable drying system with high speed rotation, automatically stop.

7. With one set printing cylinder, for 400mm printing length.

8. With 360° continuous and adjustable longitudinal register device, higher register precision.

9. With thefrequency inverter motorfor control, printing speed is adjusted by the motor..

10. Withfrequency inverterfor motor control, stable working and power saving.

Model

YT-4600

YT-4800

YT-41000

YT-41200

Max. Roll Width

600mm

800mm

1000mm

1200mm

Max. Printing Width

560mm

760mm

960mm

1160mm

Printing Length(mm)

200-1000

200-1000

200-1000

200-1000

Max. Roll Diameter

Φ 450mm

Φ 450mm

Φ 450mm

Φ 450mm

Printing Speed

5-50m/min

5-50m/min

5-50m/min

5-50m/min

Plate Thickness

2.28mm

2.38mm

2.38mm

2.38mm

Total Power

19kw

25kw

30kw

35kw

Weight of Machine

3000kg

3500kg

4000kg

4500kg
