High precision printing machine good printing quality from professional manufacturer Ruian Ruihua Printing Packing Machinery Co., Ltd.

Adopt high quality ceramic anilox cylinder to transfer the ink



 Adopt high quality ceramic anilox cylinder to transfer the ink

Unwinding adopts automatic tension controller to provide stable and constant tension control.

Each printing unit adopts 360° degree adjustment, it can independently gear and loosen, so other printing units can continue do printing.

  Each printing unit equips with IR dryer for fast ink drying.

  Equipped with web guide for tracking.

  The ink rollers will be separated from the printing rollers, and keep running when the machine stops.

  The main motor is adopted the import stepless regulation of frequency conversion.

The machine can finish material-feeding, printing, varnishing, drying, laminating, rewinding and die-cutting in one process. It is an ideal machine for printing note and top-grade adhesive label.

Main Technical Parameters

Printing speed

10-60 m/min

Printing color

4 color

Max. web width

320 mm

Max. printing width

310 mm

Max. unwinding diameter

600 mm

Max. rewinding diameter

600 mm

Printing length

160-370 mm

Max. Die Cutting Size(W*L)

300*420 mm

Total Power


If need more details, please contact
